Aluminum circles for cookware
Aluminum circles blanked at the plant from our own coil, for deep drawing and spinning. Diameters from 4.3 to 48 in, gauges from 0.018 to 0.157 in, in mill finish, pre-painted, non-stick or polychromatic.
An aluminum circle, or blank, is a flat piece blanked from rolled coil, with the diameter and gauge required by the drawing die of a pot, a pan, a steamer or a lighting fixture body.
Specifications
| Parameter | Range |
|---|---|
| Alloys | 1050, 1100, 3004, 3105 |
| Thickness | 0.018 to 0.157 in (0.45 to 4 mm) |
| Diameter | 4.3 to 48 in (110 to 1,220 mm) |
| Tempers | O for deep drawing; H12 and H14 by part |
| Finishes | Mill finish, pre-painted, non-stick, polychromatic |
| Lot certification | Mill test report with chemistry and mechanical properties |
Values from Almexa's 2021 catalog, being revalidated with the plant in September 2026. Every quote confirms the exact range for your alloy and temper.
What it is used for
- Pressure cookers, pots and steamers
- Non-stick pans and griddles
- NSF professional foodservice line
- Grills, griddles and molds
- Lamp bodies and reflectors
Industries that use it: Cookware.
What we need to quote
- Circle diameter and thickness
- Alloy and temper, or the part you will draw
- Finish: mill, pre-painted or non-stick
- Pieces per month
- Whether the circle has food contact
The sales executive confirms the delivery date in the quote, per plant schedule.
Why buy them from the mill
The circle inherits the coil's properties: if a pan base warps or a draw tears, the cause is alloy, temper or metal cleanliness. By controlling the furnace, Almexa controls all three.
Cookware makers in Mexico and the US get documented Mexican origin for USMCA and a supplier a truck ride away, not an ocean.
Applicable quality systems
- FSSC 22000 for food contact
- ISO 9001
- Mill test report per lot
Frequently asked questions
Which aluminum alloy is used for pots and pans?
For deep drawing, 1050 or 1100 in O temper: maximum ductility. For parts that need more rigidity, such as thick bases or large steamers, 3004 or 3105. Thickness runs from 0.06 to 0.157 in depending on the part.
Why does an aluminum pan base warp?
Insufficient thickness for the diameter, an alloy too soft for the use, or residual stress from rolling. The fix is usually more gauge or moving from 1100 to 3004; the sales executive reviews it with your die.
Are Almexa circles suitable for food contact?
Yes. Almexa is FSSC 22000 certified and makes circles for the NSF professional line. State in the quote that the part will have food contact.
Other products from the mill
- Aluminum coil0.008 to 0.134 in · up to 48 in · 1050, 1100, 3105
- Aluminum sheetCut to size · 0.008 to 0.134 in · 1050, 1100, 3105
- Painted aluminum sheet3105 · 0.018 to 0.049 in · up to 36 in
- Fin stock0.0039 to 0.010 in · 1100, 7072 · up to 48 in
- Pharmaceutical blister foil8079 · 16 to 22 µm · up to 6 colors + varnish
- Food packaging foil8011, 8079 · 15 to 51 µm · lacquered, embossed, laminated
Send diameter, gauge and pieces per month. We quote from the plant.
Request a quote
