Coil-coated aluminum sheet
3105 aluminum coil painted in line with high-durability baked coatings. Gauges from 0.018 to 0.049 in and widths up to 36 in. For manufacturers who need the color applied before forming, not after.
Painted, or pre-painted, aluminum sheet is cold-rolled coil coated in line with a baked paint system on one or both sides, so the formed part leaves the press with its final finish.
Specifications
| Parameter | Range |
|---|---|
| Alloy | 3105 |
| Thickness | 0.018 to 0.049 in (0.45 to 1.25 mm) |
| Width | 12 to 36 in (304.8 to 914 mm) |
| Inside diameter | 16 or 20 in (406 or 508 mm) |
| Maximum outside diameter | 51 to 59 in (1,300 to 1,500 mm) |
| Coating | Baked paint on one or two sides; non-stick and polychromatic for cookware |
| Lot certification | Mill test report and coating thickness report |
Values from Almexa's 2021 catalog, being revalidated with the plant in September 2026. Every quote confirms the exact range for your alloy and temper.
What it is used for
- Facades, gutters, ceilings and roofing
- Blinds, rolling shutters and profiles
- Appliance housings and panels
- Pre-painted and non-stick circles for pans and pots
- Signage and outdoor advertising
Industries that use it: Cookware, Construction.
What we need to quote
- Color (RAL reference or sample) and finish (matte, gloss, textured)
- One or two painted sides and backer color
- Thickness and width
- End use: exterior, interior, food contact
- Monthly volume in metric tons
The sales executive confirms the delivery date in the quote, per plant schedule.
Why buy it from the mill
Substrate and paint come from the same plant: adhesion is tested on our own 3105 coil, not on material of unknown origin.
When paint peels on a bend, it is almost always substrate temper or curing. Because we make both, we fix it at the plant.
Applicable quality systems
- ISO 9001
- Mill test report per lot
- Adhesion and coating thickness tests
Frequently asked questions
Why does paint peel off aluminum when bent?
Three causes: a temper too hard for the bend radius, incomplete paint curing or poor substrate pretreatment. Because Almexa makes coil and coating in the same plant, temper and curing are matched to the bend your process makes.
Which alloy is used for pre-painted aluminum?
3105, which combines enough strength for profiles and panels with good formability and a uniform paintable surface.
Can Almexa paint custom or short-run colors?
Quoted by volume: standard colors have lower minimums; custom colors require a minimum lot the sales executive confirms.
